Buffer Overflows on Microcontrollers

How a buffer overflow on a microcontroller becomes code execution, from input to exploitation

The stack buffer overflow is the oldest trick in the book, and on microcontrollers it still works exactly as it did decades ago. No memory management unit, no address randomization, and often writable executable memory mean a single unbounded copy can hand an attacker the whole device. Here is how it plays out on embedded firmware.

The Vulnerable Pattern

It almost always comes down to copying attacker-controlled data into a fixed-size buffer without checking the length:

Anatomy of a classic stack buffer overflow showing an unbounded strcpy into a fixed buffer

void handle(char *input) {
    char buf[64];
    strcpy(buf, input);  // no length check
    process(buf);
}

What Overflowing Does

Write past the 64 bytes and you start overwriting saved registers on the stack, including the return address. On an MCU, the crash tells the story: the program counter is now whatever you wrote:

# send 80 bytes of 'A' to the input handler
python3 -c "print('A'*80)" | ./send_to_device

Example output

[HardFault] taken
  PC = 0x41414141
  LR = 0x41414141
  Cause: INVSTATE / bus fault on 0x41414141

A program counter of 0x41414141 is the ASCII for AAAA. The input is now directly controlling where the CPU jumps, which on a device with executable RAM is one step from running attacker code.

Why MCUs Make It Worse

The mitigations that neutralized this class on servers are frequently missing on microcontrollers:

Why microcontrollers make buffer overflows worse: no MMU, no ASLR, and writable executable memory

Closing the Gap

Use bounded string functions, enable the compiler’s stack protector, mark RAM non-executable through the memory protection unit, and fuzz the input parsers. Each control on its own is partial; together they turn a reliable exploit into an unreliable crash, which is most of the battle on embedded.

Where This Fits

Finding and proving memory-safety bugs in firmware parsers is core to a product security assessment and penetration test. That analysis is the kind of work we do at Berkner Tech.
